TAL 5356

Standards

AWS/ASME SFA - 5.10 ER5356
EN ISO 18273 S Al 5356 (AlMg5Cr(A))
TS 6204 EN ISO 18273 S Al 5356 (AlMg5Cr(A))
DIN M. No. 3.3556

Properties And Applications

5% Mg (Magnesium) containing aluminium welding rod for GTA (TIG) welding of Al-Mg (Aluminimum- Magnesium) alloys and Al-Mg-Si (Aluminimum-Magnesium-Silicon) alloys. Gives colour match with base metal after anodizing process. Has excellent ductility and very good corrosion resistance especially in sea water.

Materials

DIN Material
AlMg Si 1 3.2315
G-AlMg 5 3.3561
G-AlMg 5 Si 3.3261
AlZn 4.5 Mg 1 3.4335
G-AlMg 3 Si 3.3241
AlMg 2 Mn 0.8 3.3527
Al Mg 3 3.3535
G-AlMg 3 3.3541
AlMg 5 3.3555

Typical Chemical Features of the Welding Wire

Type of AnalysisCrAlMg
Welding Wire0.1095.154.75

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)
As weldedI112027028

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :
Tal 5356 Kaynak Pozisyonu Tal 5356 Kaynak Pozisyonu Tal 5356 Kaynak Pozisyonu Tal 5356 Kaynak Pozisyonu Tal 5356 Kaynak Pozisyonu Tal 5356 Kaynak Pozisyonu

Polarity:

Tal 5356 Kutuplama

Protection Gas:

I1

Welding Parameters & Efficiency :

Diameter x Length (mm)
1.60x1000
2.00x1000
2.40x1000
3.20x1000
4.00x1000

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
24104GAKM21.60x10003 kg2.80411.30Cardboard Tube
24104GFKM21.60x10002 kg2.8048.30Plastic Box
24104HAKM22.00x10003 kg2.80411.30Cardboard Tube
24104HFKM22.00x10002 kg2.8048.30Plastic Box
24104IAKM22.40x10003 kg2.80411.30Cardboard Tube
24104IFKM22.40x10002 kg2.8048.30Plastic Box
24104LAKM23.20x10003 kg2.80411.30Cardboard Tube
24104LFKM23.20x10002 kg2.8048.30Plastic Box
24104MAKM24.00x10003 kg2.80411.30Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
