TG 171

Datasheet

Standards

AWS/ASME SFA - 5.28 ER80S-Ni2
EN ISO 636 - A W 42 9 2Ni2
TS EN ISO 636 - A W 42 9 2Ni2

Properties And Applications

Low alloyed GTA (TIG) welding rod for steels subjected to operating temperatures down to -90°C. Produces high strength and tough welded joints. Suitable to use in petrochemical, chemical, oil/gas industries and off-shore platforms, especially root and fill passes of pipes, boilers, tanks and also valves, pumps which are made of cast or forged steels.

Materials

Width DIN ASTM
11MnNi5-3
13MnNi6-3
S275NL- S460NL TStE 285 - TStE 460
S275ML - S460ML
P275NL2 - P460NL2 EStE 285 - EStE 460
P355ML2 - P460ML2
A203 (Gr A-B)
A333 - A334 (Gr 1-7)
A350 (Gr LF2-LF5-LF6)
A352 (Gr LC1-LC2)

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnNi
Welding Wire0.090.551.102.45

Typical Mechanical Values of Weld Metal(%)

Test ConditionYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As welded470 5502020°C → 200-90°C → 47
Isıl İşlem Sonrası (620°C 1 Saat)50063026-90°C → 150

Application Information

Welding Positions :
Tg 171 Kaynak Pozisyonu Tg 171 Kaynak Pozisyonu Tg 171 Kaynak Pozisyonu Tg 171 Kaynak Pozisyonu Tg 171 Kaynak Pozisyonu Tg 171 Kaynak Pozisyonu

Polarity:

Tg 171 Kutuplama

Protection Gas:

I1

Welding Parameters & Efficiency :

Diameter x Length (mm)
2.40x1000

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxKutu Brüt Ağırlığı (kg)Boxes per Outer BoxKoli Ağırlığı (kg)Packaging Type
22113IBKM22.40x10005 kg5.30421.40Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
