TG 201A

Datasheet

Standards

AWS/ASME SFA - 5.28	ER80S-D2
EN ISO 21952 - A	W Z MnMo
TS EN ISO 21952 - A	W Z MnMo

Properties And Applications

Low alloyed, GTA (TIG) welding rod for Mo-alloyed creep resisting steels, subjected to operating temperatures up to 530°C. Contains high level of deoxidizing (Mn and Si) elements to control porosity during welding. Particularly used in root and cap pass welding of steam generators joints, boilers, pressure vessels and pipes, where high X-ray quality is required. Also suitable for welding carbon steel parts subsequently heat treated after welding. Observe directions of pre- and post-weld heat treatment of base metal.

Materials

Width	DIN
P235G1TH - P255G1TH	St 35.8 - St 45.8
S255N - S460N	StE 255 - StE 460
P235GH, P265GH	H I, H II
P295GH	17Mn4
16Mo3	15 Mo 3
L360NB - L415NB	StE 360.7 - StE 415.7
L360MB - L415MB	StE 360.7 TM - StE 415.7 TM
	X52 - X60

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn	Mo
Welding Wire	0.10	0.70	1.80	0.45

Type of Analysis

Welding Wire

0.10

0.70

1.80

0.45

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	I1	540	620	26	20°C → 110	-30°C → 65

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

540

620

20°C → 110

-30°C → 65

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

Welding Parameters & Efficiency :

Diameter x Length (mm)
1.60x1000
2.00x1000
2.40x1000
3.20x1000

Diameter x Length (mm)

1.60x1000

2.00x1000

2.40x1000

3.20x1000

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
22101GBKM2	1.60x1000	5 kg	5.30	4	21.40	Cardboard Tube
22101HBKM2	2.00x1000	5 kg	5.30	4	21.40	Cardboard Tube
22101IBKM2	2.40x1000	5 kg	5.30	4	21.40	Cardboard Tube
22101LBKM2	3.20x1000	5 kg	5.30	4	21.40	Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
