TG 222A

Datasheet

Standards

AWS/ASME SFA - 5.28	ER90S-B3
EN ISO 21952 - B	W 62 2C1M
TS EN ISO 21952 - B	W 62 2C1M

Properties And Applications

Low alloyed, GTA (TIG) welding rod for Cr-Mo alloyed creep resisting steels, subjected to operating temperatures up to 600°C. Contains high level of deoxidizing (Mn and Si) elements to control porosity during welding. Particularly used in root and cap pass welding of steam generators joints, boilers, pressure vessels and pipes, where high X-ray quality is required. Also suitable for welding carbon steel parts subsequently heat treated after welding. Observe directions of pre- and post-weld heat treatment of base metal.

Materials

Width	DIN
10CrMo9-10	10 CrMo 9 10

Typical Chemical Features of the Welding Wire

Type of Analysis	C	Si	Mn	Cr	Mo
Welding Wire	0.10	0,50	0,50	2.50	1.00

Type of Analysis

Welding Wire

0.10

0,50

2.50

1.00

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
Isıl İşlem Sonrası (690°C 2 Saat)	I1	560	650	22	20°C → 110

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

Isıl İşlem Sonrası (690°C 2 Saat)

560

650

20°C → 110

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

Welding Parameters & Efficiency :

Diameter x Length (mm)
1.60x1000
2.00x1000
2.40x1000
3.20x1000

Diameter x Length (mm)

1.60x1000

2.00x1000

2.40x1000

3.20x1000

Packaging Information

Product Code	Diameter x Length (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
22105GBKM2	1.60x1000	5 kg	5.30	4	21.40	Cardboard Tube
22105HBKM2	2.00x1000	5 kg	5.30	4	21.40	Cardboard Tube
22105IBKM2	2.40x1000	5 kg	5.30	4	21.40	Cardboard Tube
22105LBKM2	3.20x1000	5 kg	5.30	4	21.40	Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
