TI 310

Standards

AWS/ASME SFA - 5.9 ER310
EN ISO 14343 - A W 25 20
TS EN ISO 14343 - A W 25 20
DIN M. No. 1.4842

Materials

EN Material ASTM
G-X15CrNi25-20 1.4840
X15CrNiSi25-21 1.4841 314
1.4842 310
X8CrNi25-21 1.4845 310S
X8CrNiTi18-10 1.4878 321H
GX25CrNiSi18-9 1.4825

Properties and Applications

Fully austenitic welding rod for GTA (TIG) welding of heat resisting steels containing approximatelly 25% chromium and 20% nickel which are used in heat treatment and industrial furnaces and equipments, like cement and steel industries. Also suited for welding heat resisting and non-scaling ferritic chromium steels, provided that corrosion attack by reducing sulphur bearing combustion gases is not to be expected. Non-scaling up to 1200°C. Weld metal exhibits good toughness values down to -196°C.
Ti 310 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnCrNi
Welding Wire0.100.401.6026.0021.00

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedI14505803620°C → 150-60°C → 100

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - I1 (%100 Ar) .

Application Information

Welding Positions :
Ti 310 Kaynak Pozisyonu Ti 310 Kaynak Pozisyonu Ti 310 Kaynak Pozisyonu Ti 310 Kaynak Pozisyonu Ti 310 Kaynak Pozisyonu Ti 310 Kaynak Pozisyonu

Polarity:

Ti 310 Kutuplama

Protection Gas:

I1

Welding Parameters & Efficiency :

Packaging Information

PRODUCT CODEDiameter x Length (mm)Quantity per box (approx.)Box Net Weight (kg)NUMBER OF BOXES IN PACKAGEPackage Net Weight (kg)Packaging Type
23104EBKM21.20x10005 kg5.0421.4Cardboard Tube
23104GBKM21.60x10005 kg5.0421.4Cardboard Tube
23104HBKM22.00x10005 kg5.0421.4Cardboard Tube
23104IBKM22.40x10005 kg5.0421.4Cardboard Tube
23104LBKM23.20x10005 kg5.0421.4Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
