TNI 422

Standards

AWS/ASME SFA - 5.14 ERNiCr-3
EN ISO 18274 - A SNi 6082
TS EN ISO 18274 - A SNi 6082
DIN M. No. 2.4806

Materials

DIN Material
X 10 Ni Cr Al Ti 32 20 1.4876
X 5 Ni Cr Al Ti 31 20 1.4958
Ni Cr 15 Fe 2.4816

Properties and Applications

Ni-Cr-Fe alloyed GTA (TIG) welding rod, depositing Ni-20Cr3Mn2,5Nb weld metal. Especially used for welding of highly creep resistant, heat and corrosion resistant Ni-Cr alloys, like Incoloy 800, 5-9% Ni containing steels, cryogenic stainless steels down to -196°C. Also suitable for joining dissimilar materials as stainless steels to low alloyed steels, stainless steels to nickel alloys, buffering of difficult to weld steels cladding on steels and repair welds of them. Weld metal deposit is insensitive to cracks, has very good resistance to acids, salts and alkaline solutions, molten salt (e.g. cyanide) in oxidizing and carburization atmospheres. In sulphuroıus atmospheres the weld metal can be used up to 500°C. Generally used for welding on LPG and LNG processing and storing plants, oven parts, burners, heat treatment equipment, cement works, moulds, transport and storage tanks of liquid gases in chemical, petrochemical industries, glassworks, civil engineering, repairing and maintenance workshops. Stick Electrode : ENI 422MIG/MAG Welding Wire: MNI 422
Tni 422 Sert Dolgu

Typical Chemical Features of the Welding Wire

Type of AnalysisCSiMnCrNiNbTiFe
Welding Wire0.030.103.0020.0072.502.400.301.30

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedI15007004020°C → 170-196°C → 160

* Chemical compositon and mechanical properties are valid when using shielding gas .

Application Information

Welding Positions :
Tni 422 Kaynak Pozisyonu Tni 422 Kaynak Pozisyonu Tni 422 Kaynak Pozisyonu Tni 422 Kaynak Pozisyonu Tni 422 Kaynak Pozisyonu Tni 422 Kaynak Pozisyonu

Polarity:

Tni 422 Kutuplama

Protection Gas:

I1

Welding Parameters & Efficiency :

Diameter x Length (mm)
1.60x1000
2.40x1000

Packaging Information

Product CodeDiameter x Length (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
26102GBKM21.60x10005 kg5.30421.40Cardboard Tube
26102IBKM22.40x10005 kg5.30421.40Cardboard Tube

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
