FCW 142

Standards

AWS/ASME SFA - 5.36 E81T-1 M21A6 Ni1
AWS/ASME SFA - 5.29 E81T1-Ni1M
EN ISO 17632 - A T46 4 1Ni P M 1 H5
TS EN ISO 17632 - A T46 4 1Ni P M 1 H5

Approvals & Certificates

Materials

Width DIN
S185 - S460 St 33- StE 460
P235TR2 - P460 St 37.4 - StE 460
P235G1TH, P255G1TH St 35.8 - St 45.8
P295 17Mn4
S255N - S420N StE 255 - StE 420
L210 - L415NB StE 210.7 - StE 415.7
L360MB - L415MB StE 360.7 TM - StE 415.7 TM
AH 32 - EH 36
X42 - X65

Properties and Applications

Rutile type flux cored wire, designed for welding fine grained structural steels by using M21 mix shielding gas. Succesfully used in single and multi-run welding in steel construction, bridge, offshore platform, shipbuilding and pipe laying. Owing to it's easily controllable weld pool and fast freezing slag, suited for welding in all position easily. It's metal recovery provides ability of good gap bridging and filling property. Because of nickel alloy, weld metal yield and tensile strength is high and weld metal is proper to use on fine grained steels at operating temperatures 450°C down to -40°C. Diffusible hydrogen content is 5 ml per 100 g deposited weld metal, so highly resistant to cold cracking. Has a stable and quite arc with low spatter loss. Has easily removable slag and generally self removed.
Fcw 142 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNi
Weld Deposit0.060.401.251.00

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2150057028-40°C → 100

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (Ar + %20 CO2) .

Application Information

Welding Positions :
Fcw 142 Kaynak Pozisyonu Fcw 142 Kaynak Pozisyonu Fcw 142 Kaynak Pozisyonu Fcw 142 Kaynak Pozisyonu Fcw 142 Kaynak Pozisyonu Fcw 142 Kaynak Pozisyonu Fcw 142 Kaynak Pozisyonu

Polarity:

Fcw 142 Kutuplama

Protection Gas:

M21

Welding Parameters & Efficiency :

Diameter (mm)
1.20

Packaging Information

Product CodeDiameter (mm)Quantity per BoxBox Gross Weight (kg)Boxes per Outer BoxOuter Box Gross Weight (kg)Packaging Type
32001ECAM21.205 kg5.4015.40Plastic Spool (D200) VAC
32001EIAM21.2015 kg16.00116.00Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
