FCW 150WM

Standards

EN ISO 17632 - A T 46 6 Z M M 1 H5

Materials

EN DIN
S235J0W
S235JRW WT St 37.2
S235J2W WT St 37-3
S355J2W WT St 52-3
S355K2W
S355J0

Properties and Applications

Nickel-Copper alloyed, metal-cored wire for single or multilayer welding of corrosion resistant steels with Ar-CO2 shielding gas. Characteristically has high efficiency, good weldability, excellent seam appearance and low spatter losses. Good mechanical properties at low temperatures. This wire is particularly suitable for bridge constructions and chimneys.
Fcw 150Wm Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnNiCu
Weld Deposit0.0320.341.360.700.46

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2148756826-50°C → 86-60°C → 64

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (Ar + %20 CO2) .

Application Information

Welding Positions :
Fcw 150Wm Kaynak Pozisyonu Fcw 150Wm Kaynak Pozisyonu

Polarity:

Fcw 150Wm Kutuplama DC(+)

Protection Gas:

M21

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
32010EJAM21.2015.0115.7Wire Basket Spool (K300MS)

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
