FCW 162

Standards

AWS/ASME SFA - 5.20 E71T-1C
EN ISO 17632 - A T55 5 Mn1.5Ni P M 1 H5
TS EN ISO 17632 - A T55 5 Mn1.5Ni P M 1 H5

Materials

EN DIN
S185 - S355J0 St 33- St 52.3
P235TR2 - P355T2 St 37.4 - St 52.4
P235G1TH, P255G1TH St 35.8 - St 45.8
P295GH 17Mn4
P235GH, P265GH H I, H II
S255N - S420N StE 255 - StE 420
L210 - L415NB StE 210.7 - StE 415.7
L290MB - L450MB StE 290.7 TM - StE 445.7 TM
GE 200, GE 240 GS 38, GS 45
AH 32 - EH 36
A, B, D, E
X42 - X65

Properties and Applications

Rutile type flux cored wire, designed for welding fine grained structural steels by using M21 shielding gas. Succesfully used in single and multi-pass welding in steel construction, offshore platform, shipbuilding and pipe laying. Provides weld metal with high toughness, down to -50°C. Diffusible hydrogen content is 5 ml per 100 g deposited weld metal, so highly resistant to cold cracking. Has a stable and quite arc with low spatter loss. Has easily removable slag and generally self removing.
Fcw 162 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisProtection GasCSiMnNi
Weld DepositM210.060.251.351.50

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2156064024-50°C → 70-60°C → 55

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 -M21 (Ar + %20 CO2) .

Application Information

Welding Positions :
Fcw 162 Kaynak Pozisyonu Fcw 162 Kaynak Pozisyonu Fcw 162 Kaynak Pozisyonu Fcw 162 Kaynak Pozisyonu Fcw 162 Kaynak Pozisyonu Fcw 162 Kaynak Pozisyonu Fcw 162 Kaynak Pozisyonu

Polarity:

Fcw 162 Kutuplama DC(+)

Protection Gas:

M21

Welding Parameters & Efficiency :

Diameter (mm)Deposition Rate(kg/h)Efficiency(%)
1.20387

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
