FCW 171

Datasheet

Standards

AWS/ASME SFA - 5.29	E81T-1 Ni2 C J
EN ISO 17632 - A	T50 6 2Ni P C 2 H5
TS EN ISO 17632 - A	T50 6 2Ni P C 2 H5

Properties And Applications

Rutile type flux cored wire, designed for welding fine grained structural steels by using CO₂ shielding gas. Succesfully used in single and multi-pass welding in steel construction, offshore platform, shipbuilding and pipe laying. Provides weld metal with high toughness, down to -60°C. Diffusible hydrogen content is 5 ml per 100 g deposited weld metal, so highly resistant to cold cracking. Has a stable and quite arc with low spatter loss. Has easily removable slag and generally self removing.

Approvals & Certificates

RMRS

Materials

Width	DIN
S185 - S460	St 33- StE 460
P235TR2 - P460	St 37.4 - StE 460
P235G1TH, P255G1TH	St 35.8 - St 45.8
P295	17Mn4
S255N - S420N	StE 255 - StE 420
L210 - L415NB	StE 210.7 - StE 415.7
L360MB - L415MB	StE 360.7 TM - StE 415.7 TM
	AH 32 - EH 36
	X42 - X65

Typical Chemical Values of Weld Metal

Type of Analysis	C	Si	Mn	Ni
Weld Deposit	0.05	0.25	1.10	2.30

Type of Analysis

Weld Deposit

0.05

0.25

1.10

2.30

Typical Mechanical Values of Weld Metal(%)

Test Condition	Protection Gas	Yield Strength (N/mm²)	Tensile Strength (N/mm²)	Elongation A5 (%)	Charpy V-Notch Properties (J)
As welded	C1	540	600	24	-50°C → 85	-60°C → 70

Test Condition

Protection Gas

Yield Strength (N/mm²)

Tensile Strength (N/mm²)

Elongation A5 (%)

Charpy V-Notch Properties (J)

As welded

540

600

-50°C → 85

-60°C → 70

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) .

Application Information

Welding Positions :

Polarity:

Protection Gas:

Welding Parameters & Efficiency :

Diameter (mm)
1.20
1.60

Diameter (mm)

1.20

1.60

Packaging Information

Product Code	Diameter (mm)	Quantity per Box	Kutu Brüt Ağırlığı (kg)	Boxes per Outer Box	Koli Ağırlığı (kg)	Packaging Type
32006ECAM2	1.20	5 kg	5.40	1	5.40	Plastic Spool (D200) VAC
32006EIAM2	1.20	15 kg	16.00	1	16.00	Plastic Spool (D300) VAC
32006GIAM2	1.60	15 kg	16.00	1	16.00	Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
