FCW 172

Standards

AWS/ASME SFA - 5.29 E81T-1-Ni2 M-J
EN ISO 17632 - A T50 6 2Ni P M21 1 H5
TS EN ISO 17632 - A T50 6 2Ni P M21 1 H5

Materials

EN DIN
S185 - S460 St 33- StE 460
P235TR2 - P460 St 37.4 - StE 460
P235G1TH, P255G1TH St 35.8 - St 45.8
P295 17Mn4
S255N - S420N StE 255 - StE 420
L210 - L415NB StE 210.7 - StE 415.7
L360MB - L415MB StE 360.7 TM - StE 415.7 TM
AH 32 - EH 36
X42 - X65

Properties and Applications

Rutile type flux cored wire, designed for welding fine grained structural steels by using M21 - mix shielding gas. Succesfully used in single and multi-pass welding in steel construction, offshore platform, shipbuilding and pipe laying which need high strength and toughness at low temperatures. Provides weld metal with high toughness, down to -60°C. Diffusible hydrogen content is 5 ml per 100 g deposited weld metal, so highly resistant to cold cracking. Has a stable and quite arc without spatter. Has easily removable slag and generally self removing.
Fcw 172 Sert Dolgu

Typical Chemical Values of Weld Metal (%)

Type of AnalysisCSiMnNi
Weld Deposit0.050.201.102.20

Typical Mechanical Values of Weld Metal

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedM2152059026-50°C → 85-60°C → 70

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - M21 (Ar + %20 CO2) .

Application Information

Welding Positions :
Fcw 172 Kaynak Pozisyonu Fcw 172 Kaynak Pozisyonu Fcw 172 Kaynak Pozisyonu Fcw 172 Kaynak Pozisyonu Fcw 172 Kaynak Pozisyonu Fcw 172 Kaynak Pozisyonu Fcw 172 Kaynak Pozisyonu

Polarity:

Fcw 172 Kutuplama DC(+)

Protection Gas:

M21

Welding Parameters & Efficiency :

Diameter (mm)Deposition Rate(kg/h)Efficiency(%)
1.20387
1.604.3387

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Boxes Per PackageWeight Of The PackagePackaging Type
32007ECBM21.205.015.4Plastic Spool (D200) VAC
32007EIAM21.2015.0116.0Plastic Spool (D300) VAC
32007GIAM21.6015.0116.0Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
