FCW 201

Standards

AWS/ASME SFA - 5.29 E81T1-A1C
EN ISO 17634 - A T MoL P C1 1 H5
EN ISO 17632 - A T 46 A Mo P C1 1 H5
TS EN ISO 17632 - A T 46 A Mo P C1 1 H5
TS EN ISO 17634 - A T MoL P C1 1 H5

Materials

EN DIN
P235G1TH - P255G1TH St 35.8 - St 45.8
P295GH, P355GH 17Mn4, 19Mn4
16Mo3 15 Mo 3
16 Mo 5
S255N - S460N StE 255 - StE 460
L360NB - L415NB StE 360.7 - StE 415.7
GP 240GH GS-C 25
G20Mo4 GS-22 Mo 4

Properties and Applications

Flux cored wire designed for welding boiler, pipe steels, steam generators and other equipments, subjected to operating temperatures up to 500°C. Suitable to use in all position welding and preferred to use where high mechanical properties and X-ray quality are required.
Fcw 201 Sert Dolgu

Typical Chemical Values of Weld Metal

Type of AnalysisCSiMnMo
Weld Deposit0.030.351.100.40

Typical Mechanical Values of Weld Metal(%)

Test ConditionProtection GasYield Strength (N/mm²)Tensile Strength (N/mm²)Elongation A5 (%)Charpy V-Notch Properties (J)
As weldedC15306002220°C → 90

* Chemical compositon and mechanical properties are valid when using shielding gas EN ISO 14175 - C1 (%100 CO2) .

Application Information

Welding Positions :
Fcw 201 Kaynak Pozisyonu Fcw 201 Kaynak Pozisyonu Fcw 201 Kaynak Pozisyonu Fcw 201 Kaynak Pozisyonu Fcw 201 Kaynak Pozisyonu Fcw 201 Kaynak Pozisyonu Fcw 201 Kaynak Pozisyonu

Polarity:

Fcw 201 Kutuplama DC(+)

Protection Gas:

C1

Welding Parameters & Efficiency :

Packaging Information

Product CodeDiameter (mm)Weight Of The Box (kg)Number Of Boxes Per PackageWeight Of The PackagePackaging Type
32004EIAM21.2015.0116.0Plastic Spool (D300) VAC
32004GIAM21.6015.0116.0Plastic Spool (D300) VAC

Storage & Re-Drying Information

>Shouldn t be exposed to high statical load and impact.
